Windmill Magnet Alternator

Windmill Magnet Alternator

25000 - 38000 INR/Set

Product Details:

  • Protection Class IP 54
  • Alternator Wind turbine Alternator
  • Poles Number 16
  • Insulation H Class
  • Product Type Radial Flux PMG
  • Output Type three phase
  • Rated Power 1
  • Supply Ability : 100 Set Per Month
  • Click to view more
X

Price And Quantity

  • 25000.00 - 38000.00 INR/Set
  • 1 Set
  • 25000 - 38000 INR/Set

Product Specifications

  • 16
  • 50 Hertz (HZ)
  • Radial Flux PMG
  • IP 54
  • 415 Volt (V)
  • Wind turbine Alternator
  • 35 Kilograms (kg)
  • 1
  • Grey
  • H Class
  • 50 Hertz (HZ)
  • three phase
  • 24 Months
  • Three Phase
  • 1000 Watt (w)

Trade Information

  • Paypal, Cheque, Cash in Advance (CID), Cash Advance (CA)
  • 100 Set Per Month
  • 15 Days
  • Yes
  • Wooden Box
  • Africa, Western Europe, Eastern Europe, Australia, Asia
  • All India
  • CE, ISO

Product Description

Product details

Technical Specification for 1KW, 375 RPM, 415VAC, Three Phase Permanent Magnet Alternator.

Description

Parameter



Rated Power

1 KW



RPM

375



Number of Pole

16



Rated Voltage

415 Volts (Three-Phase)



Power Factor

0.9



Rated Amp

1.5 Amps



Frequency

50 Hz



Insulation Class

H Class



Working Temperature

-30⁰ C to 80⁰ C



Starting Torque

0.36 NM



Rated Torque

25 NM



Magnet Type

Neodymium (NdFeB)



Warranty

24 Months



Type

Radial Flux Foot Mounting



Generator shell material

Cast Iron



Winding material

100% Copper



Shaft material

EN8



Bearing Brand

SKF



Efficiency

More than 90%



Protection

IP54






J. D. ENGINEERING WORKS
